The state pattern is useful when an object’s behavior is determined by its state given sufficient complexity. Events trigger the transition of a state to another. A formalized construct that manages the transitions is called a state machine.

To implement the pattern, we need to define:

• A state entry and exit behaviors
• Actions when a particular event causes a transition
• Guard conditions enabling and disabling a transition
• default actions when no transition is required for a particular event

For example, companies often used automated phone system to redirect and filter calls. We are given choices and depending on the choices, we are given specific answers or redirected to a person. This example is perfect for the state pattern. We can maintain a state object of the phone call and create rules that list the different options depending on the choices the caller made or redirect the call to another phone number.

The Mediator pattern facilitates communication between components without having references to each other. It avoids tight coupling between components and helps maintainability.

Let’s say we are building a user interface to visualizes photos. There are multiple components such as the image, the title, the author, the image exif info, the comments, the thumbnail bar, etc. When a user selects a new image, all those components need to be updated. Without the Mediator pattern, the “next” button would call all the components to update them.

public class NextButton {

 private Display imageDisplay;
 private Label title;
 private Label author;
 ...

 public onClick() {
    // some code to get the image
    imageDisplay.goto(image);
    title.set(image);
    author.set(image);
    // etc...
 }
}

We can also imagine that adding a comment would update the title of the image with the total count of comments. It would mean that the comment section has a reference on the title. All those components would be tightly linked.

The Mediator pattern introduces a new component which would be the only one with references to all the different components. Whenever a component needs to communicate with the others, it would send a message to the mediator which then dispatch it to the others.

In our case, the click on “Next” would send an event.

public class NextButton implements UIComponent {

 private EventBroker mediator;

 public void onClick() {
     // some code to get the image
     mediator.publish(new Event("updateImage"));
 }

 public void listen(Event e) {
   // do something when necessary
 }
}

The mediator would then publish the events to all the components that are listening.

public class EventBroker {
    private List<UIComponent> components;

   public void subscribe(UIComponent component) {
     components.add(component);
   }

   public void publish(Event e) {
     components.foreach(it -> it.listen(e));
   }
}

The interpreter pattern evaluates textual inputs. It does it by turning it into separated lexical terms (lexing) and interpreting each sequence (parsing). You can think of programming languages, or languages meant to carry information such as XML.

For example, we want to calculate the result of this formula: 1+3+5*7

First, we need to find the terms: [1,3,5,7] and the operations: [+, +, *]

Second, we interpret them into a logical sequence: add(add(1,3),multiply(5,7)).

The idea is to single out terms and operations in order to simplify and make the design flexible to different inputs (ex: term order, etc.)

The Command Pattern is useful to implement an instruction to perform a particular action. It contains and encapsulates all the information necessary for the action to be taken. It can allow to create composite commands, to keep track of a sequence of commands, and possibly to undo one of the commands. It can be used in GUI or transactions for example.

Think of a text editor. We can type characters and format them. Each command will implement an interface:

public interface Command {
   void perform();
   void undo();
}

public class Write implements Command {

   private TextEditor editor; // we will assume this class exists.
   private String string;
   private boolean success;

   public Write(TextEditor editor, String string) {
      this.editor = editor;
      this.string = string;
      this.success = false; // by default, a boolean is false, but it does not hurt to make it explicit!
   }

   @Override
   public void perform() {
       editor.write(string);
       success = true;
   }

   @Override
   public void undo() {
      if (success) { // we do not want to undo if the operation failed
        editor.erase(string); // more complex in reality, but not the purpose of this example.
      }
   }
}

public class Formatter implements Command {

  public enum Format {
     BOLD,
     ITALICIZE
  }

   private TextEditor editor;
   private Format format;
   private int startPosition;
   private int endPosition;
   private boolean success;

   public Formatter(TextEditor editor, Format format, int startPosition, int endPosition) { // could chain with Write.. Chain of responsibility pattern!
      this.editor = editor;
      this.format = format;
      this.startPosition = startPosition;
      this.endPosition = endPosition;
      this.success = false;
   }

   @Override
   public void perform() {
      switch (format) {
         case BOLD:
           success = editor.bold(startPosition, endPosition);
           break;
         case ITALICIZE:
           success = editor.italicize(startPosition, endPosition);
           break;
         default:
           break;
      }
   }

   @Override
   public void undo() {
      if (!success) return; // we do not want to undo if the operation failed
      switch (format) {
        case BOLD:
          editor.unbold(startPosition, endPosition);
          break;
        case ITALICIZE:
          editor.unbold(startPosition, endPosition);
          break;
        default:
          break;
      }
   }
}

The client code can chain commands or undo, etc.

TextEditor editor = new TextEditor();
Command awesome = new Write(editor, "This is awesome!");
Command author = new Write(editor, "By John Doe");
Command formatAwesome = new Formatter(editor, Formatter.Format.BOLD, 8, 15);
Command formatAuthor = new Formatter(editor, Formatter.Format.ITALICIZE, 16, 27);

List<Command> cmds = new ArrayList<>();
cmds.add(awesome);
cmds.add(formatAwesome);
cmds.add(author);
cmds.add(formatAuthor);

try {
  cmds.forEach(Command::perform); // run
} catch (Exception e) {
  Collections.reverse(cmds); // reverse the command sequence.
  cmds.forEach(Command::undo); // will undo only those that succeeded.
}

This pattern can be combined with the Chain of Responsibility pattern or the Strategy pattern.

This is awesome! But is it really useful you could ask? What about just calling TextEditor’s methods? True! I was wondering the same. What is really powerful is how we can manage those commands. It can be more complex commands, sequenced, and we can create rollbacks, etc.

The Chain of Responsibility pattern is useful when there is a chain of components that need to accomplish the same operation. Each component may have a default implementation and/or cancel the processing chain.

Let’s say we want to write a class that handles http requests. For each request, we want to log it, verify its authentication, and parse the content. Each operation can be designed as a class implementing the same interface.

public interface HttpRequestHandler {

   HttpRequestHandler next();
   void setNext(HttpRequestHandler next);

   // allows to chain other handlers
   default void add(HttpRequestHandler handler) {
      if (next() != null) {
        next().add(handler);
      } else {
        setNext(handler);
      }
   };

   void process(HttpRequest request);
}

public class Logger implements HttpRequestHandler {

   private Log log = ...
   private HttpRequestHandler next;

   // implements getter/setter
   // ...

   public void process(HttpRequest request) {
      log.log(request); // order can changed if we want the operations to start at the end of the chain
      if (next != null) next.process(request);
   }
}

public class Authenticator implements HttpRequestHandler {

    private HttpRequestHandler next;

    // implements getter/setter
    // ...

    public void process(HttpRequest request) {
      if (authenticate(request)) {
         if (next != null) next.process(request);
      }
      // the chain is disrupted if the request does not pass the security check
    }

    private boolean authenticate(HttpRequest request) {
      // ...
    }
}


public class Parser implements HttpRequestHandler {

    private HttpRequestHandler next;

    // implements getter/setter
    // ...

    public void process(HttpRequest request) {
      parse(request);
      if (next != null) next.process(request);
    }

    private void parse(HttpRequest request) {
       // ...
    }
}

The good thing with this design is that we can add more operations without too much effort. Now we can have our client code manipulating the handlers:

public class WebServer {

   public HttpResponse respondTo(HttpRequest request) {
      handlers().handle(request);
   }

   private HttpRequestHandler handlers() {
      Logger logger = new Logger();
      Authenticator auth = new Authenticator();
      Parser parser = new Parser();
      logger.add(auth);
      logger.add(parser);
      return logger;
   }

}
